RUIJIE RG-RAP6260(H) - WIFI 6 6000 MBPS ACCESS POINT
- Ultra-fast 5.95 Gbit/s outdoor Wi-Fi 6, best-in-class Wi-Fi performance.
- Easily adding extra outdoor Wi-Fi with Reyee mesh.
- Long-distance deployment with optical ports.
- IP68 rating, adapting to harsh environments.
- Internet access with 2.5 Gbit/s uplink.
- Lightning Protection/Surge ±4kV (Including DC port)
Customize
Share :
The Ruijie Reyee RG‑RAP6260(H) is a premium Wi‑Fi 6 AX6000 high‑density outdoor omni‑directional access point engineered for ultra‑fast, long‑range and highly reliable wireless connectivity in demanding outdoor environments. Designed with a fully sealed IP68‑rated enclosure, it delivers exceptional durability against rain, dust, humidity, wind erosion and extreme temperatures, making it ideal for parks, beaches, stadiums, warehouses, traffic stations, plazas, playgrounds and large commercial outdoor spaces.
Powered by advanced 802.11ax (Wi‑Fi 6) technology, the RG‑RAP6260(H) delivers an impressive combined wireless throughput of 5950 Mbps, including 4803 Mbps on the 5 GHz band and 1147 Mbps on 2.4 GHz. Its dual‑radio 4×4 MU‑MIMO architecture provides eight spatial streams, enabling efficient communication with large numbers of clients simultaneously and dramatically improving network responsiveness in high‑density outdoor environments.
Enhanced RF performance is achieved through 4× eFEM amplifiers on both 2.4 GHz and 5 GHz, delivering stronger signal penetration and stable long‑distance coverage. In ideal open‑air conditions, the RG‑RAP6260(H) reaches up to 400 metres on 5 GHz and 150 metres on 2.4 GHz, with recommended ranges of 200 m and 50 m respectively. Its eight built‑in high‑gain omnidirectional antennas ensure wide, uniform coverage suitable for large outdoor deployments.
Engineered for extreme reliability, the RG‑RAP6260(H) features ±4 kV lightning protection, flame‑retardant materials, and an operating temperature range of –40°C to +65°C, ensuring stable performance in harsh weather conditions.
To support long‑distance outdoor networking, the RG‑RAP6260(H) includes both a 2.5 Gbps Ethernet uplink port and a Gigabit SFP optical port, enabling fiber backhaul for extended deployments. This makes it ideal for remote sites, distributed campuses and long‑range point‑to‑point or point‑to‑multipoint networks.
The RG‑RAP6260(H) integrates seamlessly with the Ruijie Cloud Management Platform, offering centralised configuration, remote monitoring, wireless optimisation, cloud portal authentication and effortless multi‑AP deployment. Features such as Reyee Mesh, OFDMA, 1024‑QAM, 160 MHz channel width, DFS radar detection, Layer‑2/Layer‑3 roaming, and load balancing ensure stable, secure and professionally managed outdoor Wi‑Fi.
Security is enterprise‑grade, with support for WPA‑PSK, WPA2‑PSK, WPA/WPA2‑PSK, blacklist/whitelist controls and frequency‑hopping mechanisms for DFS compliance. The device supports up to 512 clients, with 130 recommended for optimal performance — ideal for stadiums, public venues, outdoor hospitality, retail exteriors and multi‑AP mesh deployments.
Perfect for parks, beaches, stadiums, warehouses, traffic stations, plazas, playgrounds and large outdoor commercial spaces, the RG‑RAP6260(H) combines AX6000 performance, long‑range omni‑directional coverage, multi‑gigabit uplink capability and rugged IP68 durability. It stands as one of the most powerful and advanced outdoor Wi‑Fi 6 access points in the Reyee lineup, delivering exceptional speed, stability and cloud‑based simplicity for modern outdoor networks.
